• 4 Horse Angle Standard Horse Float

    If your looking for style and comfort for your horses then look no further than Gladiator Horse Floats. The Gladiator 4 Horse Angle Load - Standard Horse Float is spacious in design, offering comfort and style for your precious horses during transportation.

    This 4 Horse Angle Load horse float offered by Gladiator Horse Floats is easy to drive around and has many features added to the horse float at no additional cost.

    We make the Horse Bays Facing either Left or Right as well as Reverse facing Left or Right.

  • 4 Horse Float Measurements

    Inside Dimensions:
    Length: 5275mm
    Width: 1980mm
    Standard Height: 2225mm
    Extended Height: 2325mm Optional Extra $800
    Tare Weight: 1700kg approximately
    Gross Weight: 3500kg

  • 4 Horse Float Price

    $32,800.00 (incl. GST)

  • 4 Angle Load Standard Horse Float Specifications

    Chassis Material:
    Galvanised, Frame Material - Galvanised, Body panel - Aluminium, Wheel Rims - 4 x 14' Mag Wheels (Optional extra 15" Mag or Sunraysia) plus Spare 14" Mag or Sunraysia Wheels under Lock and key Plus Spare Wheel Mounted above Drawbar or where you prefer. 2 x 50mm solid 50mm, Roll Rocker Tandem Suspension 9 springs, Double Axle Electric Brakes, Breakaway System Fitted to Float (Independent braking system that activates itself when float becomes detached from towing vehicle).

    We also make our floats partially aluminium - the frame and chassis are still steel for strength and flexibility, but the outside sheeting/cladding is aluminium, thicker aluminium and same strength as steel and still corrugated for strength where the horses are. By having the sheeting aluminium, we are lessoning the weight and also eliminating rust forever as aluminium doesn't rust. Basically, everything that is non-structural is now aluminium.

    Plus, the benefit for the horses is that it is actually cooler inside the float than your standard steel float. Steel absorbs heat and retains it whereas aluminium dissipates it leaving the float walls cool to touch which in turn makes it cool inside the float. It's a win for both human and horses so to speak.

    6 sliding Windows tinted and with fly screen, 4 Pop Up Vents approx.400mm x 250mm, Pop Up Barn Doors with high intensity anti rust strut and special copper hinges or optional extra Swing Open to the side Barn Doors, Ramp Door fitted with high intensity anti rust struts, Draw bar filled in with Checker Plate, Mudguard covered with Checker Plate
    Filled in Checker Plate on Rear Light Panels, 2 Draw bar Safety Chains, Fully Padded Dividers and rump Pad, 4 Stainless Steel recessed tie up rings on the outside of the horse float.

    Horse Float Lighting:
    Rear LED Lights with Reverse Light, 6 Side Amber Lights, 8 Retro Reflectors. Internal 12v LED Lights - one above front entry door and second at rear of float for night time loading.

    Horse Float Flooring:

    We install a safety feature in the float so that no horses can ever go through the float floor.

    A 4mm thick aluminium plate/sheet gets installed in the chassis.

    How the aluminium sheet works is that it guarantees that your horses will never go through the floor of your float.

    First you have the already reinforced chassis which we use square tubing not angle bar across the width of the float along the whole length of the float at 500mm apart then we use angle bars lengthways to brace everything together like a chessboard. Then we install the 4mm thick aluminium plate and then the 22mm thick honeycomb flooring and then the non slip rubber matting and that is then all glued down so that the float becomes waterproof and you can wash the float out the more the better. The layering of the different materials also can help eliminate road noise.

    Nonslip rubber floor matting installed on tailgate  ....fully sealed and waterproof, Nonslip rubber matting for ramp door with extra footing support with horizontal mounded rubber panels. Rubber matting on kickboard and pawboard,

    Float:
    Fully enclosed Side Rug Rack, Swing out Tack Box Fully lined with 3 saddle holders and bridle hooks, lockable and waterproof and can be left outside with tailgate closed. Fly Screen on all windows. Fully Lockable float.

    Paint Work: 2 pack paint work White as standard with black trim around windows, side door, barn doors and black and aluminium trim around top side of the horse float. Tinted Windows.

    Horse Float Bay Dimensions:
    Measurements are taken from the middle of the front bay to the middle of the back bay.

    • 1st Bay 2400mm (Bay closest to front window)
    • 2nd bay 2500mm
    • 3rd Bay 2500mm
    • 4th Bay 2500mm

    The bay measurement of the Horse Transport Truck is 2280mm. We measured 2 separate Horse Transport trucks that are used for the transport of race horses which are usually between 15h - 17h.

    The horses in the trucks stand in their bays sideways (not on an angle). This should give you some indication of the length of our horse float bays compared to the Horse Transport Truck bays.

  • Need Further Information About This Horse Float?

    Should you need further information or have questions relating to this horse float or any other Gladiator Horse Float on our site, please contact us by completing the contact form or contact us by calling 1300 445 234
